Description

Explore the Behringer DeepMind 12 Synthesizer from Behringer. Below you will find product details, specifications and images to help you decide whether it is right for your setup.

The Deepmind represents Behringer’s first foray into true polyphonic analog synthesis. The Deepmind 12, as the name suggests, is a 12-note polysynth that’s bursting at the seams with features – even more impressive when you consider the price tag.

Key features

• Polyphonic synthesiser with 49-note keybed and fader control interface
• 12 voices with 2 analog OSCs per voice with oscillator sync mode
• 2 LFOs per voice with 7 waveform shapes, key sync, MIDI sync and envelope auto-triggering
• 3 ADSR generators per voice for control of VCF, VCA and MOD envelopes
• Selectable dual slope 12/24 dB analog low pass filter per voice with adjustable resonance
• Flexible 8-channel modulation matrix with 19 sources and over 130 destinations including effects parameters
• 4 FX slots with world-class TC Electronic and Klark Teknik FX
• 32-step control sequencer with adjustable slew rate and MIDI sync
• Sophisticated built-in arpeggiator
• Full remote control via iPad*/PC/Mac* App over USB or MIDI for extended parameter control
• 37 semi-weighted full-size keys featuring velocity sensitivity and after-touch
• Stereo audio output
• CV/pedal input for connection to modular systems
• LCD display for easy menu navigation
• 1024 user preset slots
• Designed and engineered in the UK

12-Voice Polyphonic Control

The Deepmind 12 is a true polysynth behemoth. Even when you take out the extensive FX, modulation matrix and connectivity (more on this later), you’ve got 12 voices with 2 oscillators per voice. OSC 1 generates sawtooth and square/pulse waveforms with pulse width modulation, while OSC 2 generates square/pulse waveforms with tone modulation.

It doesn’t stop there though. 2 LFOs per voice let you easily inject movement into your sound, with 7 shapes, key sync and automatic triggering for easy synchronising. You’ll also get 3 ADSR envelopes per voice for VCF, VCA and modulation respectively – unprecedented control. Finally a 12/24dB low-pass filter per-voice lets you hone in on the perfect amount of light or dark.

Cutting-Edge Effects

Behringer often work closely with renowned FX wizards TC Electronic and Klark Teknik; the Deepmind is no exception. With 4 simultaneous FX slots, you can make the most of any combination of over 30 algorithms, from reverb to multi-band distortion. Combined with the extensive 32-step sequencer and arpeggiator, and you’ve got a powerhouse of a synth toolkit on your hands.

The 8-channel modulation matrix lets you weave complex textures and patches of your own, with over 130 destinations. Finally, a stereo audio output and CV connectivity completes the puzzle, making the Deepmind 12 a synthesiser that’s perfect for stage as well as studio.

Included in the box

• Power Supply PSU-3b
• USB cable
• Quick Guide manual

Technical Specifications

Global

• Display: Backlit LCD
• Main Menus: PROG, FX, GLOBAL, COMPARE, WRITE
• Edit Menus: ARP/SEQ, LFOs, OSCs, POLY, VCF, VCA, VCA ENV, VCF ENV, MOD ENV, MOD MATRIX
• Presets: 8 banks each with 128 programs
• Fader Modes: MIDI CC, NRPN, OFF

Controls

• Keyboard: 49 semi-weighted, full-size keys
• Keyboard sensing: Aftertouch and note on/off velocity
• Encoders: 1 rotary knob
• Faders: 26 slide faders (35 mm)
• Switches: 33 backlit switches
• Modulation: Free moving wheel
• Pitch Bend: Spring loaded wheel

Connectivity

• MIDI In/Out/Thru: 5-pin DIN / 16 channels
• Pedal/CV: 1/4″ TRS
• Sustain: 1/4″ TS
• USB: USB 2.0, type B
• Output L/R: 1/4″ TRS, balanced, max. +18 dBu
• Headphones: 1/4″ TRS, unbalanced, max. +21 dBu

Synthesizer Architecture

• Number of voices: 12 analog
• OSC: 2 per voice
• LFO: 2 per voice
• VCF: 2-pole / 4-pole
• HPF (Common to all voices): 6 dB per octave
• Envelopes: VCA, VCF, MOD
• Mod Matrix: 24 sources / 132 destinations

Digital Effects

• FX Slots: 4 per Program
• FX Types: 35 Algorithms
• Internal effects engines: 1 true stereo SHARC DSP
• Effects signal processing: 32/40-bit floating point @ 48 kHz
• A/D-D/A performance: 24-bit 48 kHz, 114 dB dynamic range
• Bypass: True hard bypass

USB

• Type: Class compliant USB 2.0, type B
• Supported operating systems: Windows 7 or higher, Mac OS X 10.6.8 or higher, iOS 8 or higher (iPad), Android 6.0 or higher

Wi-Fi

• Antenna: Internal
• Access Point, number of clients: Max. 1
• IEEE 802.11 b/g standard: 2.4 GHz
• Frequency Range: 2,412 – 2,462 MHz
• WLAN channels: 11
• Max Output Power: 16 dBm (802.11b) / 20 dBm (802.11 g) / 20 dBm (802.11n)

Power

• Mains connector: Standard IEC receptacle
• Power consumption: 55 W max.
• Fuse: T3.15AH250 V
• Internal Switch-mode PSU: Autorange 100-240 V, (50/60 Hz)

Environmental

• Operating temperature range: 5°C – 40°C (41°F – 104°F)

Physical (Packaged)

• Dimensions (H x W x D) 103 x 822 x 257 mm
• Weight: 8.4 kg
• Shipping Weight: 10.5 kg
