Description

What's included in this Bundle

• Roland SPD-SX-PRO Sampler Percussion Pad
• Roland PDS-20 Percussion Pad Stand
• Roland Black Series SPD / SX Bag
• Roland RH5 Headphones

About the Roland SPD-SX-PRO

Roland present the SPD-SX PRO, their new flagship sampling percussion pad. Packed full with features including nine playing surfaces, eight external trigger inputs, colour display, customizable pad LEDs and onboard effects, the Roland SPD-SX PRO is the ultimate sampling pad for any kind of gig or recording session. With years of extensive user feedback from the previous SPD-S and SPD-SX models, the SPD-SX PRO raises the bar to a new level!

The SPD-SX PRO harnesses the advanced sample pad technology of its predecessors and adds to this with an array of requested enhancements making it perfect for life on the road. Customisable multi-colour trigger lights along with a large colour display will illuminate dark stages meaning you'll never be struggling to see what's going on. Use the on-board audio outputs, additional trigger inputs, and hi-hat and FX expression pedal control to expand your performance setup to a new level. With a massive 32 GB memory, 48 kHz audio playback, and a dedicated SPD-SX PRO App for easier kit editing, the SPD-SX PRO is a top-tier solution for any sampling pad requirements!

Key Features

• Nine pads with Roland’s advanced trigger technology, including six large pads and three top-row shoulder pads
• High-visibility, horizontal and vertical LEDs with multi-colour customization
• Increased shoulder pad sensitivity and improved crosstalk performance
• 4.3-inch colour display for easy navigation and viewing during performance
• Import 48/44.1 kHz (16-/24-/32-bit) WAV/AIFF files and MP3s (32–320 kbps) with automatic conversion to 48 kHz/16-bit upon loading
• Stereo main output, four direct mono outputs, balanced for easy mixing on stage
• Connectivity for up to eight external individual triggers/pads (four stereo triggers or eight mono triggers with Y-cables)
• Dedicated SPD-SX PRO App for Windows/Mac for easy importing, managing samples, and deep kit editing
• 32 GB of internal storage for samples, backing tracks, and click tracks
• Input for hi-hat or footswitch expression control
• Connect hi-hats, kick, and snare for a ‘mini drum kit’ setup
• Up to 200 kit patches (43 erasable preset kits and 157 user kits)
• Over 1550 pre-loaded, high-quality samples and sounds
• 16-step pad sequencer function
• Onboard effects engine with up to four effects in parallel, plus side chain with output routing
• Built-in click/metronome
• Create in real time by recording performances as WAV files and assigning them to pad

Specifications

Pads

• Built-in pads: 9 (with PAD LED, Vertical LED)
• * Four external trigger inputs are provided, allowing you to connect up to eight pads with Y cable.

Maximum Polyphony

• 32 voices (included click voices)

Number of Recordable Wave Data

• 20,000 *Including preload data

Internal storage

• Size: 32 GB *Including preload data

Sampling Time

• Sampling from AUDIO IN : 60 minutes per sample
• Resampling : 10 minutes per sample

Data Format

• 16-bit linear

Sampling Frequency

• 48 kHz
• Import Format

WAV, AIFF, MP3

• Kits: 200

Preload wave

• Factory preloaded samples: 1,550 or more

Setlist

• 32 (32 steps per SET LIST)

Kit Effects

• Layer Equalizer : each pad (Layer A/B independently)
• Layer Transient : each pad (Layer A/B independently)
• Multi-Effects (53 types) : 4 systems
• Side Chain Compressor : 1 system

System Effects

• Master Effects (53 types)
• Master Compressor
• Master Equalizer

Number of USB Audio Record/Playback Channels

• Sampling Rate (Original): 48 kHz
• Sampling Rate (with Sampling rate converter): 96 kHz, 44.1 kHz
• Record: 8 channels
• Playback: 12 channels

Display

• Graphic colour LCD 4.3 inch

Connectors

• PHONES jack : Stereo 1/4-inch phone type
• MASTER OUT (L, R)jacks (BALANCED) : 1/4-inch TRS phone type
• DIRECT OUT jack x 4 (BALANCED) : 1/4-inch TRS phone type
• AUDIO IN jack : Stereo 1/4-inch phone type (with Volume control)
• TRIG IN jack x 4 (1/2, 3/4, 5/6, 7/8) : 1/4-inch TRS phone type
• FOOT SW jack x 1 (1/2) : 1/4-inch TRS phone type
• HH CTRL/EXPRESSION jack x 1 : 1/4-inch TRS phone type
• MIDI (IN, OUT/THRU) connectors
• USB COMPUTER port : USB B (High-Speed USB, USB-AUDIO, USB-MIDI, App)
• USB MEMORY port : USB A (High-Speed USB, Backup Save/Load, Sample Import/Export)
• DC IN jack

Power Supply

• DC 12V (AC Adaptor)

Current Draw

• 1,500 mA

Dimensions

• 360 (W) x 330.3 (D) x 92.9 (H) mm

Weight

• 3.0 kg (excluding AC Adaptor)

Accessories

• AC adaptor
• Quick Start Guide
• Owner’s Manual

Optional Accessories (Sold Separately)

• Pads (PD series, PDX series, BT-1)
• Cymbals (CY series)
• Hi-Hat (VH-10, VH-11)
• Kick Triggers (KD series, KT series)
• Pad Stand (PDS-20, PDS-10)
• All-Purpose Clamp (APC-33)
• Acoustic Drum Trigger (RT-30K, RT-30HR, RT-30H)
• Hi-Hat Pedal(FD-8, FD-9, VH-10, HV-11)
• Expression Pedal(BOSS EV-30)
• Pedal Switch(DP-2)
• Foot Switch (BOSS FS-5U, FS-6, FS-7)
• Y cable (PCS-31L)
• USB Flash Memory
